Filtry wentylacyjne Acro 37 TF z membraną PTFE

Filtry wentylacyjne z membraną PTFE.
Acro™ 37 TF vent device With PTFE membrane, a Pall Life Sciences product, is used in-line to deliver air and gas to instruments and culture vessels

Venting and Gas Filtration
PTFE membrane and polypropylene housing have broad chemical compatibility
Disposable - Eliminates the cost and labor associated with disc-loaded stainless steel filter holders
Economical -Available in bulk packaging

Materials of Construction
Filter Media: PTFE on a polypropylene support
Housing: Polypropylene

Effective Filtration Area
7.5 cm2

Overall Length: 5.3 cm (2.1 in.)
Diameter: 4.5 cm (1.8 in.)

Inlet/Outlet Connections
Stepped hose barbs, 6.4 - 9.5 mm (1/4 - 3/8 in.) diameter

Maximum Operating Temperature
100°C (212°F)

Maximum Operating Pressure
4.1 bar (410 kPa, 60 psi)

Minimum Water Breakthrough
2.1 bar (210 kPa, 30 psi), bi-directional

Recommended Integrity Test Minimum Bubble Point
̶ IPA, 100%
0.9 bar (90 kPa, 13 psi)

Typical Air Flow Rate
3.58 L/min at 0.
2 bar (20 kPa, 3 psi)

Provided non-sterile
Autoclavable if desired 121 - 123°C (250 - 253°F) for a maximum of 20 min.

Use in-line for air/gas delivery to instruments and culture vessels, for bioisolation of a vacuum source, or for flushing instruments and cleaning parts
Can be used to filter small volumes of liquid solvents
Filtry wentylacyjne Acro 37 TF z membraną PTFE
Product Product Name Effective filtration area Pore size - removal rating Connections
4465 0.2 µm  37 mm (200/pkg) 7.5 cm˛ 0.2 µm Stepped Hose Barb
4464 37 TF 0.2 µm PTFE 24/PK 7.5 cm˛ 0.2 µm Stepped Hose Barb
