HEPA-Cap Vent Filters

Opis produktu

36 mm HEPA filter media are used throughout the scientific, research, and industrial environments in a variety of air and gas filtration applications where high retention, dirt-holding capacity, and flow rates are required.

• Glass filter media strengthened by dual lamination with a tough polyester monofilament.
• Retains 99.97% of all particles ≥ 0.3 µm in air.
• Allows bidirectional flow.
• Depth filter design allows for high loading capacity.
• Tissue culture applications.

Specyfikacja

Housing	Polypropylene (PP)
Operating pressure max.	4.1 bar (60 psi)
Dimensions	36 mm
Filter Media	Laminated hydrophobically treated glass microfiber
Flow Direction	Bidirectional
Sterilization	Autoclavable
Sealing	Heat-fused
Support System	Polypropylene (PP)
Nominal filtration area	36 mm capsule: ca. 625 cm²

Informacje do zamówienia

Nr kat.	Opis produktu	Opakowanie
2609T	HEPA-CAP 36, inlet 3/8" FNPT, outlet 3/8" FNPT	5 pieces
6702-3600	HEPA-CAP 36, inlet 1/4 to 3/8" stepped barb, outlet 1/4 to 3/8" stepped barb	1 piece
2709T	HEPA-CAP 75, inlet 3/8" FNPT, outlet 3/8" FNPT	5 pieces
6702-7500	HEPA-CAP 75, inlet 3/8stepped barb, outlet 3/8 stepped barb	1 piece
2809T	HEPA-CAP 150, inlet 3/8" FNPT, outlet 3/8" FNPT	5 pieces
6702-9500	HEPA-CAP 150, inlet 3/8" FNPT, outlet 3/8" FNPT	1 piece

Powiązane dokumenty

Whatman HEPA-CAP Instructions for Use
Instruction for use
