Filtry membranowe Supor PES
Przeznaczone do filtracji biologicznej, farmaceutycznej i sterylizacji.
Supor™ PES membrane disc filters, a Pall Life Sciences product, are high flow rate membranes optimized for biological, pharmaceutical, and sterilizing filtration requirements.

    High flow rate membrane optimized for biological, pharmaceutical, and sterilizing filtration requirements
    Fast filtration with superior flow rates and high throughputs
    Low protein binding and extensive drug compatibility for critical applications
    Saves time and money with fewer filter changes per sample volume
    142 and 293 mm discs feature printed tab for instant recognition of pore size and lot number

Applications
    Suited for biological, pharmaceutical, and sterilizing filtration requirements
    Available for microbiological analysis in individual packaging
Filtry membranowe Supor PES
Filter Media
Hydrophilic polyethersulfone (PES)

Pore Size
0.1, 0.2, 0.45, and 0.8 μm

Diameter
13 - 293 mm

Typical Thickness
0.1 μm: 132 μm (5.2 mils)
0.2 μm: 145 μm (5.7 mils)
0.45 and 0.8 μm: 140 μm (5.5 mils)

Typical Water Flow Rate
mL/min/cm2 at 0.7 bar (70 kPa, 10 psi)
0.1 μm: 5
0.2 μm: 26
0.45 μm: 58
0.8 μm: 165

Maximum Operating Temperature - Water
100°C (212°F)

Extractables - Soxhlet Extraction
< 4%

Minimum Bubble Point - Water
0.2 μm: 3.5 bar (350 kPa, 51 psi)
0.45 μm: 2.5 bar (250 kPa, 36 psi)
0.8 μm: 1.0 bar (100 kPa, 15 psi)
60% IPA/40% H2O (v:v)
0.1 μm: 2.4 bar (240 kPa, 35 psi)

Biological Safety
Passes United States Pharmacopeia (USP) Biological Reactivity Test, In Vivo <88>

Sterilization
Provided non-sterile. Can be sterilized by autoclaving at 121 - 123°C (250 - 253°F) for 30 min. PN 63025, 60043, 65472 and 66234 are provided gamma-irradiated.

Applications
Suited for biological, pharmaceutical, and sterilizing filtration requirements
Available for microbiological analysis in individual packaging
Nr kat. Opis produktu Pory Średnica Przekładka Opak.
66234 Supor PES membrane disc filters, 0,2 um, 47 mm, gridded, sterile, individually sealed, gamma irradiated, bulk w/ parchment separators, no tab (200/pkg) 0,2 um 47 mm No tab 200
60114 Supor PES membrane disc filters, 0,8 um, 142 mm, with tab (25/pkg) 0,8 um 142 mm With tab 25
60305 Supor PES membrane disc filters, 0,2 um, 142 mm, with tab (25/pkg) 0,2 um 142 mm With tab 25
60309 Supor PES membrane disc filters, 0,1 um, 25 mm, plain, no tab (100/pkg) 0,1 um 25 mm No tab 100
60310 Supor PES membrane disc filters, 0,1 um, 47 mm, plain, no tab (100/pkg) 0,1 um 47 mm No tab 100
66549 Supor PES membrane disc filters, 0,2 um, 142 mm, no tab (25/pkg) 0,2 um 142 mm No tab 25
66550 Supor PES membrane disc filters, 0,2 um, 293 mm, no tab (25/pkg) 0,2 um 293 mm No tab 25
66552 Supor PES membrane disc filters, 0,1 um, 293 mm, no tab (25/pkg) 0,1 um 293 mm No tab 25
66553 Supor PES membrane disc filters, 0,45 um, 142 mm, no tab (25/pkg) 0,45 um 142 mm No tab 25
61854 Supor PES membrane disc filters, 0,45 um, 47 mm, grid, no tab (100/pkg) 0,45 um 47 mm No tab 100
60179 Supor PES membrane disc filters, 0,45 um, 293 mm, with tab (25/pkg) 0,45 um 293 mm With tab 25
60173 Supor PES membrane disc filters, 0,45 um, 47 mm, plain, no tab (100/pkg) 0,45 um 47 mm No tab 100
60206 Supor PES membrane disc filters, 0,45 um, 90 mm, plain, no tab (100/pkg) 0,45 um 90 mm No tab 100
60175 Supor PES membrane disc filters, 0,45 um, 102 mm, no tab (100/pkg) 0,45 um 102 mm No tab 100
60311 Supor PES membrane disc filters, 0,1 um, 90 mm, plain, no tab (100/pkg) 0,1 um 90 mm No tab 100
60043 Supor PES membrane disc filters, 0,45 um, 47 mm, gridded, sterile, individually sealed, gamma irradiated, bulk w/ parchment separators, no tab (200/pkg) 0,45 um 47 mm No tab 200
60112 Supor PES membrane disc filters, 0,8 um, 90 mm, plain, no tab (100/pkg) 0,8 um 90 mm No tab 100
60170 Supor PES membrane disc filters, 0,45 um, 13 mm, plain, no tab (100/pkg) 0,45 um 13 mm No tab 100
66555 Supor PES membrane disc filters, 0,8 um, 142 mm, no tab (25/pkg) 0,8 um 142 mm No tab 25
66556 Supor PES membrane disc filters, 0,8 um, 293 mm, no tab (25/pkg) 0,8 um 293 mm No tab 25
60301 Supor PES membrane disc filters, 0,2 um, 47 mm, plain, no tab (100/pkg) 0,2 um 47 mm No tab 100
60177 Supor PES membrane disc filters, 0,45 um, 142 mm, with tab (25/pkg) 0,45 um 142 mm With tab 25
65472 Supor PES membrane disc filters, 0,8 um, 47 mm, gridded, sterile, individually sealed, gamma irradiated, bulk w/ parchment separators, no tab (200/pkg) 0,8 um 47 mm No tab 200
60174 Supor PES membrane disc filters, 0,45 um, 50 mm, plain, no tab (100/pkg) 0,45 um 50 mm No tab 100
60300 Supor PES membrane disc filters, 0,2 um, 25 mm, plain, no tab (100/pkg) 0,2 um 25 mm No tab 100
60307 Supor PES membrane disc filters, 0,2 um, 293 mm, with tab (25/pkg) 0,2 um 293 mm With tab 25
60312 Supor PES membrane disc filters, 0,1 um, 142 mm, with tab (25/pkg) 0,1 um 142 mm With tab 25
60334 Supor PES membrane disc filters, 0,2 um, 90 mm, plain, no tab (100/pkg) 0,2 um 90 mm No tab 100
60172 Supor PES membrane disc filters, 0,45 um, 25 mm, plain, no tab (100/pkg) 0,45 um 25 mm No tab 100
66554 Supor PES membrane disc filters, 0,45 um, 293 mm, no tab (25/pkg) 0,45 um 293 mm No tab 25
66551 Supor PES membrane disc filters, 0,1 um, 142 mm, no tab (25/pkg) 0,1 um 142 mm No tab 25
60298 Supor PES membrane disc filters, 0,2 um, 13 mm, plain, no tab (100/pkg) 0,2 um 13 mm No tab 100
60116 Supor PES membrane disc filters, 0,8 um, 293 mm, with tab (25/pkg) 0,8 um 293 mm With tab 25
60109 Supor PES membrane disc filters, 0,8 um, 25 mm, plain, no tab (100/pkg) 0,8 um 25 mm No tab 100
60110 Supor PES membrane disc filters, 0,8 um, 47 mm, plain, no tab (100/pkg) 0,8 um 47 mm No tab 100
